x| Приложение | Аудио и видео | Рейтинг тока | 30 а |
|---|---|---|---|
| Пол | Мужчина/женщина | IP -уровень | IP40 |
| Тип | Громкоговоритель | Промышленная электроника | Аксессуары |
| Выделить | High Quality 8 Pin Loudspeakers Connector,Polyamide Shell 8 Pin Loudspeakers Connector |
||
Connection Type | speakON |
Gender | Female |
Contact resistance | ≤ 3 mΩ (after lifetime) |
Dielectric strength | 4 kVdc (peak) |
Insulation resistance | > 1 GΩ (after dampheat) |
Rated current per contact | 30 A rms continuous |
Rated current per contact | A audiosignal, duty cycle 50 % |
Rated voltage | 250 V ac |
Attention | speakON is NOT to be used as an AC mains or power supply connector! |
Cable O.D. | 8-20mm |
Cable retention | ≥ 220 N (subject to cable O.D. and material) |
Lifetime | > 5000 mating cycles |
Wire size | 4 mm² |
Wire size | 12 AWG |
Wiring | screw type terminals or soldering |
Locking device | Quick Lock (latch) |
Contact plating | 4 µm Ag |
Contacts | Brass (CuZn39Pb3) |
Insert | PBTP 20 % GR |
Locking element | Zinc diecast (ZnAl4Cu1) |
Shell | Polyamide (PA 6 30 % GR) |
Strain relief | Polyacetal (POM) |
Flammability | UL 94 HB |
Solderability | Complies with IEC 68-2-20 |
Temperature range | -30 °C to +80 °C |
